HgCdTe (MCT) Photoconductive Detectors
Photoconductive detectors based on the photoconductive effect. Infrared radiation generates charge carriers in the semiconductor active region decreasing its resistance. The resistance change is sensed as a current change by applying a constant voltage bias.
The devices are characterized by near linear current-voltage characteristics. The electric field in photoconductors is constant across the device.
Engineering sample
Filter results
Name
Cooling
Immersion
Peak wavelength
λpeak, µm
Detectivity
D* (λpeak), cm⋅Hz1/2/W
Time constant
τ, ns
Package
Datasheet
Cooling
no
Immersion
Yes
Wavelength
8.2±0.1
Detectivity
~1.4×10\(^{7}\)
Time constant
~2
Package
TO39
Filter results
Selected Line
Filter results
Name
Cooling
Immersion
Optimal wavelength
λopt; µm
Detectivity
D* (λopt); cm⋅Hz1/2/W
Time constant
τ, ns
Package
Datasheet
Cooling
3TE
Immersion
Yes
Wavelength
12.0
Detectivity
≥ 9.0×10\(^{8}\)
Time constant
≤ 5
Package
TO8
Filter results
All HgCdTe (MCT) Photoconductive Detectors
Filter results
Name
Cooling
Immersion
Optimal wavelength
λopt; µm
Detectivity
D* (λopt); cm⋅Hz1/2/W
Time constant
τ, ns
Package
Datasheet
Cooling
no
Immersion
No
Wavelength
6.0
Detectivity
≥ 3.0×10\(^{8}\)
Time constant
≤ 500
Package
BNC, TO39
Cooling
no
Immersion
No
Wavelength
5.0
Detectivity
≥ 1.0×10\(^{9}\)
Time constant
≤ 5000
Package
BNC, TO39
Cooling
no
Immersion
No
Wavelength
9.0
Detectivity
≥ 2.0×10\(^{7}\)
Time constant
≤ 10
Package
BNC, TO39
Cooling
no
Immersion
No
Wavelength
10.6
Detectivity
≥ 9.0×10\(^{6}\)
Time constant
≤ 3
Package
BNC, TO39
Cooling
2TE
Immersion
No
Wavelength
5.0
Detectivity
≥ 1.0×10\(^{10}\)
Time constant
≤ 20000
Package
TO8, TO66
Cooling
2TE
Immersion
No
Wavelength
6.0
Detectivity
≥ 3.0×10\(^{9}\)
Time constant
≤ 4000
Package
TO8, TO66
Cooling
2TE
Immersion
No
Wavelength
9.0
Detectivity
≥ 4.5×10\(^{8}\)
Time constant
≤ 40
Package
TO8, TO66
Cooling
2TE
Immersion
No
Wavelength
10.6
Detectivity
≥ 1.4×10\(^{8}\)
Time constant
≤ 10
Package
TO8, TO66
Cooling
2TE
Immersion
No
Wavelength
12.0
Detectivity
≥ 4.5×10\(^{7}\)
Time constant
≤ 3
Package
TO8, TO66
Cooling
2TE
Immersion
No
Wavelength
13.0
Detectivity
≥ 2.3×10\(^{7}\)
Time constant
≤ 2
Package
TO8, TO66
Cooling
3TE
Immersion
No
Wavelength
9.0
Detectivity
≥ 1.0×10\(^{9}\)
Time constant
≤ 60
Package
TO8, TO66
Cooling
3TE
Immersion
No
Wavelength
10.6
Detectivity
≥ 2.5×10\(^{8}\)
Time constant
≤ 20
Package
TO8, TO66
Cooling
3TE
Immersion
No
Wavelength
12.0
Detectivity
≥ 9.0×10\(^{7}\)
Time constant
≤ 5
Package
TO8, TO66
Cooling
3TE
Immersion
No
Wavelength
13.0
Detectivity
≥ 6.0×10\(^{7}\)
Time constant
≤ 4
Package
TO8, TO66
Cooling
4TE
Immersion
No
Wavelength
9.0
Detectivity
≥ 1.5×10\(^{9}\)
Time constant
≤ 80
Package
TO8, TO66
Cooling
4TE
Immersion
No
Wavelength
10.6
Detectivity
≥ 3.5×10\(^{8}\)
Time constant
≤ 30
Package
TO8, TO66
Cooling
4TE
Immersion
No
Wavelength
12.0
Detectivity
≥ 2.0×10\(^{8}\)
Time constant
≤ 7
Package
TO8, TO66
Cooling
4TE
Immersion
No
Wavelength
13.0
Detectivity
≥ 1.0×10\(^{8}\)
Time constant
≤ 6
Package
TO8, TO66
Cooling
4TE
Immersion
No
Wavelength
14.0
Detectivity
≥ 6.0×10\(^{7}\)
Time constant
≤ 5
Package
TO8, TO66
Cooling
no
Immersion
Yes
Wavelength
5.0
Detectivity
≥ 4.0×10\(^{9}\)
Time constant
≤ 5000
Package
BNC, TO39
Cooling
no
Immersion
Yes
Wavelength
6.0
Detectivity
≥ 1.0×10\(^{9}\)
Time constant
≤ 500
Package
BNC, TO39
Cooling
no
Immersion
Yes
Wavelength
9.0
Detectivity
≥ 1.0×10\(^{8}\)
Time constant
≤ 10
Package
BNC, TO39
Cooling
no
Immersion
Yes
Wavelength
10.6
Detectivity
≥ 8.0×10\(^{7}\)
Time constant
≤ 3
Package
BNC, TO39
Cooling
2TE
Immersion
Yes
Wavelength
5.0
Detectivity
≥ 2.0×10\(^{10}\)
Time constant
≤ 20000
Package
TO8, TO66
Cooling
2TE
Immersion
Yes
Wavelength
6.0
Detectivity
≥ 1.0×10\(^{10}\)
Time constant
≤ 4000
Package
TO8, TO66
Cooling
2TE
Immersion
Yes
Wavelength
9.0
Detectivity
≥ 4.0×10\(^{9}\)
Time constant
≤ 40
Package
TO8, TO66
Cooling
2TE
Immersion
Yes
Wavelength
10.6
Detectivity
≥ 1.0×10\(^{9}\)
Time constant
≤ 10
Package
TO8, TO66
Cooling
2TE
Immersion
Yes
Wavelength
12.0
Detectivity
≥ 4.5×10\(^{8}\)
Time constant
≤ 3
Package
TO8, TO66
Cooling
2TE
Immersion
Yes
Wavelength
13.0
Detectivity
≥ 2.3×10\(^{8}\)
Time constant
≤ 2
Package
TO8, TO66
Cooling
3TE
Immersion
Yes
Wavelength
9.0
Detectivity
≥ 6.2×10\(^{9}\)
Time constant
≤ 60
Package
TO8, TO66
Cooling
3TE
Immersion
Yes
Wavelength
10.6
Detectivity
≥ 2.5×10\(^{9}\)
Time constant
≤ 20
Package
TO8, TO66
Cooling
3TE
Immersion
Yes
Wavelength
12.0
Detectivity
≥ 9.0×10\(^{8}\)
Time constant
≤ 5
Package
TO8, TO66
Cooling
3TE
Immersion
Yes
Wavelength
13.0
Detectivity
≥ 4.5×10\(^{8}\)
Time constant
≤ 4
Package
TO8, TO66
Cooling
4TE
Immersion
Yes
Wavelength
9.0
Detectivity
≥ 1.0×10\(^{10}\)
Time constant
≤ 80
Package
TO8, TO66
Cooling
4TE
Immersion
Yes
Wavelength
10.6
Detectivity
≥ 3.0×10\(^{9}\)
Time constant
≤ 30
Package
TO8, TO66
Cooling
4TE
Immersion
Yes
Wavelength
12.0
Detectivity
≥ 2.0×10\(^{9}\)
Time constant
≤ 7
Package
TO8, TO66
Cooling
4TE
Immersion
Yes
Wavelength
13.0
Detectivity
≥ 1.0×10\(^{9}\)
Time constant
≤ 6
Package
TO8, TO66
Cooling
4TE
Immersion
Yes
Wavelength
14.0
Detectivity
≥ 3.0×10\(^{8}\)
Time constant
≤ 5
Package
TO8, TO66
