Selected Line

SM Series

Filter results

close-icon


Name

Optimal wavelength

?

\(λ_{opt}\); \(µm\)

Optical area

?
\(A₀, mm×mm\)

Detectivity

?

\(D*(λ_{opt})\); \(cm⋅Hz^{1/2}/W\)

Output voltage responsivity

?

\(R_{V}(λ_{opt}, R_{L}=50Ω)\), V/W

-3dB Bandwidth

Datasheet

Wavelength

12.0

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 1.3×10\(^{9}\)

Output voltage

≥ 6.3×10\(^{4}\)

Bandwidth

10 Hz to 1MHz

Filter results

icon-filter icon-filter

UM Series

Filter results

close-icon


Name

Optimal wavelength

?

\(λ_{opt}\); \(µm\)

Optical area

?
\(A₀, mm×mm\)

Detectivity

?

\(D*(λ_{opt})\); \(cm⋅Hz^{1/2}/W\)

Output voltage responsivity

?

\(R_{V}(λ_{opt}, R_{L}=50Ω)\), V/W

-3dB Bandwidth

Datasheet

Wavelength

6.0

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 1.5×10\(^{10}\)

Output voltage

≥ 3.6×10\(^{4}\)

Bandwidth

DC to ≥ 1 MHz

Wavelength

10.6

Optical area

1×1

Detectivity

≥ 4.2×10\(^{7}\)

Output voltage

≥ 1.0×10\(^{2}\)

Bandwidth

DC to ≥ 70 MHz

Wavelength

10.6

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 3.7×10\(^{8}\)

Output voltage

≥ 6.5×10\(^{2}\)

Bandwidth

DC to ≥ 100 MHz

Filter results

icon-filter icon-filter

LabM Series

Filter results

close-icon


Name

Optimal wavelength

?

\(λ_{opt}\); \(µm\)

Optical area

?
\(A₀, mm×mm\)

Detectivity

?

\(D*(λ_{opt})\); \(cm⋅Hz^{1/2}/W\)

Output voltage responsivity

?

\(R_{V}(λ_{opt}, R_{L}=50Ω)\), V/W

-3dB Bandwidth

Datasheet

Wavelength

4.0

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 1.2×10\(^{10}\)

Output voltage

≥ 2.3×10\(^{4}\)

Bandwidth

DC/10 Hz to ≥ 5 MHz

Wavelength

5.0

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 1.0×10\(^{10}\)

Output voltage

1×1 (hyperhemiimmersion microlens)

Bandwidth

DC/10 Hz to ≥ 15 MHz

Wavelength

6.0

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 7.2×10\(^{9}\)

Output voltage

≥ 2.0×10\(^{4}\)

Bandwidth

10 Hz to ≥ 200 MHz

Wavelength

6.0

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 7.0×10\(^{9}\)

Output voltage

≥ 3.5×10\(^{4}\)

Bandwidth

DC/10 Hz to ≥ 3 MHz

Wavelength

10.6

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 6.0×10\(^{8}\)

Output voltage

≥ 2.0×10\(^{3}\)

Bandwidth

DC to ≥ 100 MHz

Filter results

icon-filter icon-filter

UHSM Series

Filter results

close-icon


Name

Optimal wavelength

?

\(λ_{opt}\); \(µm\)

Optical area

?
\(A₀, mm×mm\)

Detectivity

?

\(D*(λ_{opt})\); \(cm⋅Hz^{1/2}/W\)

Output voltage responsivity

?

\(R_{V}(λ_{opt}, R_{L}=50Ω)\), V/W

-3dB Bandwidth

Datasheet

Wavelength

10.6

Optical area

0.05×0.05

Detectivity

≥ 3.0×10\(^{8}\)

Output voltage

≥ 3.0×10\(^{3}\)

Bandwidth

300 Hz to ≥ 1.0 GHz

Wavelength

10.6

Optical area

1×1 (hyperhemiimmersion microlens)

Detectivity

≥ 1.0×10\(^{9}\)

Output voltage

≥ 7.0×10\(^{2}\)

Bandwidth

300 Hz to ≥ 700 MHz

Filter results

icon-filter icon-filter

MicroM Series

Filter results

close-icon


Name

Optimal wavelength

?

\(λ_{opt}\); \(µm\)

Optical area

?
\(A₀, mm×mm\)

Detectivity

?

\(D*(λ_{opt})\); \(cm⋅Hz^{1/2}/W\)

Output voltage responsivity

?

\(R_{V}(λ_{opt}, R_{L}=50Ω)\), V/W

-3dB Bandwidth

Datasheet

Wavelength

10.6

Optical area

1×1

Detectivity

≥ 5.0×10\(^{6}\)

Output voltage

≥ 8.0×10\(^{1}\)

Bandwidth

DC to ≥ 10 MHz

Filter results

icon-filter icon-filter
