home-icon/Products / Infrared Detections Modules / Heatsink MHS-2

HeatsinkMHS-2

MHS-2 is an external heatsink made of black anodized aluminium, dedicated for OEM VIGO detection modules integrated with TE cooled detectors and preamplifier SIP-TO8. It provides suitable dissipation of heat generated by the Peltier cooler. Its thermal ressistance is ~1.5 K/W.

See specification
MHS-2-1

Download datasheet

download-icon

See related files

arrow-white

Mechanical layout, mm

Technical drawing of a metal bracket with detailed measurements. The top view shows a horizontally symmetrical design, while the bottom view displays a rectangular plate with multiple screw holes and grooves, including precise dimensions in millimeters.
